Freestanding; 3 Regular; 1 ADA – Stainless Steel Bathroom Stalls

This stainless steel toilet partitions plan supplies 3 regular stalls with right hand inswing doors and 1 ADA stall with a right hand outswing door. Hadrian stainless has 91% (76% post-consumer 15% pre-consumer) recycled content and is resistant to harsh cleaning chemicals and detergents. Ask about optional special finishes.
Starting at
Standard Colors
Anti-Graffiti Colors
Special Effects Colors

Layout Detail

Layout410 - Freestanding; 3 Regular; 1 ADA
Layout Code410
HeadrailsHeadrail-braced configuration includes 60", 72" or 90" headrails cut to length
Hardware Materialchrome plated (stainless optional upgrade)
ADA Stall Depth60" Typical
ADA Stall Width60.5" Typical
Standard Stall Depth60" Typical
Standard Stall Width36" Typical
Alcove Channels0
Headrail Brackets4
Headrail End Caps2
F Brackets4
U Brackets10
H Brackets6
Coathook Bumpers4
Shoes (Stainless)4
Regular Stalls3
Alcove Stalls0
Box Stalls1
